Polyolefin Heat Shrink Tube: Ensures secure connections and protection.
High-Performance Connector: Reduces signal distortion and improves communication quality.
Gold Plated Components: Enhances conductivity and durability.
Customizable Options: Tailored solutions for various applications.
Strict Quality Control: Rigorous testing ensures reliable performance.
High-Performance RF Connector Engineered for uncompromising performance, our RF connector sets a new standard in signal integrity and reliability.
Designed to meet MIL-STD-348 and IEC 60169-15 specifications, this component delivers exceptional broadband capability from DC to 18 GHz, with a VSWR of just 1.2 at DC~3GHz for minimal signal loss.
Crafted with precision, the connector features a brass body and center conductor with gold plating, paired with PTFE insulators and a phosphor bronze C'Ring. This construction ensures outstanding electrical performance-with contact resistance ≤3mΩ (center conductor) and insulation resistance ≥5000MΩ-while providing robust durability and corrosion resistance.
Backed by a 1000V dielectric withstand voltage and protected by a silicone rubber gasket and polyolefin heat shrink tube, our connector is built to thrive in the most demanding environments. Whether for aerospace, telecommunications, or industrial applications, it offers the reliability and performance you can trust.
